Описание товара
Software | Cisco Unified Wireless Network Software Release 8.9.x or laterCisco IOS® XE Software Release 16.11 with AP Device Pack, or later |
Supported wireless LAN controllers | Cisco Catalyst 9800 Series Wireless ControllersCisco 3500, 5520, and 8540 Series Wireless Controllers and Cisco Virtual Wireless Controller |
802.11n version 2.0 (and related) capabilities | 4x4 MIMO with four spatial streamsMaximal Ratio Combining (MRC)802.11n and 802.11a/g beamforming20- and 40-MHz channelsPHY data rates up to 890 Mbps (40 MHz with 5 GHz and 20 MHz with 2.4 GHz)Packet aggregation: A-MPDU (transmit and receive), A-MSDU (transmit and receive)802.11 Dynamic Frequency Selection (DFS)Cyclic Shift Diversity (CSD) support |
802.11ac | 4x4 downlink MU-MIMO with four spatial streamsMRC802.11ac beamforming20-, 40-, 80-, and 160-MHz channelsPHY data rates up to 3.47 Gbps (160 MHz with 5 GHz)Packet aggregation: A-MPDU (transmit and receive), A-MSDU (transmit and receive)802.11 DFSCSD support |
802.11ax | 4x4 downlink MU-MIMO with four spatial streamsUplink/downlink OFDMATWTBSS coloringMRC802.11ax beamforming20-, 40-, 80-, and 160-MHz channelsPHY data rates up to 5.38 Gbps (160 MHz with 5 GHz and 20 MHz with 2.4 GHz)Packet aggregation: A-MPDU (transmit and receive), A-MSDU (transmit and receive)802.11 DFSCSD support |
Integrated antenna | Flexible radio (either on 2.4GHz or on 5GHz)2.4 GHz, peak gain 4 dBi, internal antenna, omnidirectional in azimuth5 GHz, peak gain 5 dBi, internal antenna, omnidirectional in azimuthDedicated 5GHz radio5 GHz, peak gain 4 dBi, internal antenna, omnidirectional in azimuth |
External antenna (sold separately) | Cisco Catalyst 9120E Access Points are certified for use with antenna gains up to 6 dBi (2.4 GHz and 5 GHz)Cisco Catalyst 9120P Access Points) are certified for use with antenna gains up to 13 dBi (2.4 GHz and 5 GHz)With the AIR-ANT2513-P4M-N= antennaCisco offers the industry's broadest selection of antennas, delivering optimal coverage for a variety ofDeployment scenariosSupports Self-Identifiable Antennas (SIA) on one RP-TNC port |
Smart Antenna Connector | Available on the 9120E and on the 9120P onlyCompact multi RF connector with DART interfaceRequires the AIR-CAB002-DART-R= 2 ft smart antenna connector when used with antennas with RP-TNCConnectorRequired when running the flexible radio as either a second 5-GHz serving radio or a Wireless SecurityMonitoring radio |
Interfaces | 1x 100, 1000, 2500 Multigigabit Ethernet (RJ-45)–IEEE 802.3bzManagement console port (RJ-45)USB 2.0 @ 3.75W (enabled via future software) |
Indicators | Status LED indicates boot loader status, association status, operating status, boot loader warnings, and boot loader errors |
Dimensions (W x L x H) | Access point (without mounting brackets): C9120I: 8.5 x 8.5 x 1.7' (21.6 x 21.6 x 4.3 cm), C9120E andC9120P: 8.5 x 8.05x 2.0' (21.6 x 21.6 x 5.1 cm) |
Input power requirements | 802.3at Power over Ethernet Plus (PoE+), 802.3bt Cisco Universal PoE (Cisco UPOE+, Cisco UPOE®)Cisco power injector, AIR-PWRINJ6=802.3af PoECisco power injector, AIR-PWRINJ5= (Note: This injector supports only 802.3af) |
Environmental | Cisco Catalyst 9120AXINonoperating (storage) temperature: -22° to 158°F (-30° to 70°C)Nonoperating (storage) altitude test: 25?C, 15,000 ft.Operating temperature: 32° to 122°F (0° to 50°C)Operating humidity: 10% to 90% (noncondensing)Operating altitude test: 40?C, 9843 ft.Note: When the ambient operating temperature exceeds 40°C, the access point will shift from 4x4 to2x2 on both the 2.4-GHz and 5-GHz radios, uplink Ethernet will downgrade to 1 Gigabit Ethernet,However, the USB interface will remain enabledCisco Catalyst 9120AXE and 9120AXPNonoperating (storage) temperature: -22° to 158°F (-30° to 70°C)Nonoperating (storage) altitude test: 25?C, 15,000 ft.Operating temperature: -4° to 122°F (-20° to 50°C)Operating humidity: 10% to 90% (noncondensing)Operating altitude test: 40?C, 9843 ft. |
System memory | 2048 MB DRAM1024 MB flash |
Warranty | Limited lifetime hardware warranty |
Available transmit power settings | 2.4 GHz23 dBm (200 mW)20 dBm (100 mW)17 dBm (50 mW)14 dBm (25 mW)11 dBm (12.5 mW)8 dBm (6.25 mW)5 dBm (3.13 mW)2 dBm (1.56 mW)-1dBm (0.79mW)-4dBm(0.39mW)5 GHz26 dBm (400 mW)23 dBm (200 mW)20 dBm (100 mW)17 dBm (50 mW)14 dBm (25 mW)11 dBm (12.5 mW)8 dBm (6.25 mW)5 dBm (3.13 mW)2 dBm (1.56 mW)-1dBm (0.79mW) |
Frequency band and 20-MHz operating channels | E (E regulatory domain):2.412 to 2.4835, 13 channels5.150 to 5.350 GHz, 8 channels5.470 to 5.725 GHz, 8 channels |
Производитель | Cisco |
Основные характеристики
- 802.11ac
- 4x4 downlink MU-MIMO with four spatial streamsMRC802.11ac beamforming20-, 40-, 80-, and 160-MHz channelsPHY data rates up to 3.47 Gbps (160 MHz with 5 GHz)Packet aggregation: A-MPDU (transmit and receive), A-MSDU (transmit and receive)802.11 DFSCSD support
- 802.11ax
- 4x4 downlink MU-MIMO with four spatial streamsUplink/downlink OFDMATWTBSS coloringMRC802.11ax beamforming20-, 40-, 80-, and 160-MHz channelsPHY data rates up to 5.38 Gbps (160 MHz with 5 GHz and 20 MHz with 2.4 GHz)Packet aggregation: A-MPDU (transmit and receive), A-MSDU (transmit and receive)802.11 DFSCSD support
- 802.11n version 2.0 (and related) capabilities
- 4x4 MIMO with four spatial streamsMaximal Ratio Combining (MRC)802.11n and 802.11a/g beamforming20- and 40-MHz channelsPHY data rates up to 890 Mbps (40 MHz with 5 GHz and 20 MHz with 2.4 GHz)Packet aggregation: A-MPDU (transmit and receive), A-MSDU (transmit and receive)802.11 Dynamic Frequency Selection (DFS)Cyclic Shift Diversity (CSD) support
- Available transmit power settings
- 2.4 GHz23 dBm (200 mW)20 dBm (100 mW)17 dBm (50 mW)14 dBm (25 mW)11 dBm (12.5 mW)8 dBm (6.25 mW)5 dBm (3.13 mW)2 dBm (1.56 mW)-1dBm (0.79mW)-4dBm(0.39mW)5 GHz26 dBm (400 mW)23 dBm (200 mW)20 dBm (100 mW)17 dBm (50 mW)14 dBm (25 mW)11 dBm (12.5 mW)8 dBm (6.25 mW)5 dBm (3.13 mW)2 dBm (1.56 mW)-1dBm (0.79mW)
- Dimensions (W x L x H)
- Access point (without mounting brackets): C9120I: 8.5 x 8.5 x 1.7' (21.6 x 21.6 x 4.3 cm), C9120E andC9120P: 8.5 x 8.05x 2.0' (21.6 x 21.6 x 5.1 cm)
- Environmental
- Cisco Catalyst 9120AXINonoperating (storage) temperature: -22° to 158°F (-30° to 70°C)Nonoperating (storage) altitude test: 25?C, 15,000 ft.Operating temperature: 32° to 122°F (0° to 50°C)Operating humidity: 10% to 90% (noncondensing)Operating altitude test: 40?C, 9843 ft.Note: When the ambient operating temperature exceeds 40°C, the access point will shift from 4x4 to2x2 on both the 2.4-GHz and 5-GHz radios, uplink Ethernet will downgrade to 1 Gigabit Ethernet,However, the USB interface will remain enabledCisco Catalyst 9120AXE and 9120AXPNonoperating (storage) temperature: -22° to 158°F (-30° to 70°C)Nonoperating (storage) altitude test: 25?C, 15,000 ft.Operating temperature: -4° to 122°F (-20° to 50°C)Operating humidity: 10% to 90% (noncondensing)Operating altitude test: 40?C, 9843 ft
- External antenna (sold separately)
- Cisco Catalyst 9120E Access Points are certified for use with antenna gains up to 6 dBi (2.4 GHz and 5 GHz)Cisco Catalyst 9120P Access Points) are certified for use with antenna gains up to 13 dBi (2.4 GHz and 5 GHz)With the AIR-ANT2513-P4M-N= antennaCisco offers the industry's broadest selection of antennas, delivering optimal coverage for a variety ofDeployment scenariosSupports Self-Identifiable Antennas (SIA) on one RP-TNC port
- Frequency band and 20-MHz operating channels
- E (E regulatory domain):2.412 to 2.4835, 13 channels5.150 to 5.350 GHz, 8 channels5.470 to 5.725 GHz, 8 channels
- Indicators
- Status LED indicates boot loader status, association status, operating status, boot loader warnings, and boot loader errors
- Input power requirements
- 802.3at Power over Ethernet Plus (PoE+), 802.3bt Cisco Universal PoE (Cisco UPOE+, Cisco UPOE®)Cisco power injector, AIR-PWRINJ6=802.3af PoECisco power injector, AIR-PWRINJ5= (Note: This injector supports only 802.3af)
- Integrated antenna
- Flexible radio (either on 2.4GHz or on 5GHz)2.4 GHz, peak gain 4 dBi, internal antenna, omnidirectional in azimuth5 GHz, peak gain 5 dBi, internal antenna, omnidirectional in azimuthDedicated 5GHz radio5 GHz, peak gain 4 dBi, internal antenna, omnidirectional in azimuth
- Interfaces
- 1x 100, 1000, 2500 Multigigabit Ethernet (RJ-45)–IEEE 802.3bzManagement console port (RJ-45)USB 2.0 @ 3.75W (enabled via future software)
- Smart Antenna Connector
- Available on the 9120E and on the 9120P onlyCompact multi RF connector with DART interfaceRequires the AIR-CAB002-DART-R= 2 ft smart antenna connector when used with antennas with RP-TNCConnectorRequired when running the flexible radio as either a second 5-GHz serving radio or a Wireless SecurityMonitoring radio
- Software
- Cisco Unified Wireless Network Software Release 8.9.x or laterCisco IOS® XE Software Release 16.11 with AP Device Pack, or later
- Supported wireless LAN controllers
- Cisco Catalyst 9800 Series Wireless ControllersCisco 3500, 5520, and 8540 Series Wireless Controllers and Cisco Virtual Wireless Controller
- System memory
- 2048 MB DRAM1024 MB flash
- Warranty
- Limited lifetime hardware warranty
- Производитель
- Cisco
