Product Compatibility | Fully compatible with standards-compliant telepresence and video systems | |
Software Compatibility | Cisco TelePresence Software Version TC4.0 or later | |
Components | Fully integrated unit including: • Codec • Display • Camera • Microphone and loudspeakers • Cables including: VGA-to-DVI-I cable, DVI-D cable, 3.5-mm jack audio cable, LAN cable, power adapter, and power cable | |
Display | • EX90 • 24-in. LCD monitor • Resolution: 1920 x 1200 (16:9) • Contrast ratio: 1000:1 • Viewing angle: 160° • Response time: 5 ms • Brightness: 300cd/m2 • 5° - 15° tilt | • EX60 • 21.5-in. LCD monitor (with LED backlight) • Resolution: 1920 x 1080 (16:9) • Contrast ratio: 1000:1 • Viewing angle: 170° • Response time: 5 ms • Brightness: 225cd/m2 |
PC and second-source video input | DVI-IEX90: HDMI In. | |
Supported PC input resolutions | EX90: SVGA (800 x 600) to WUXGA (1920 x 1200)EX60: SVGA (800 x 600) to 1080p (1920 x 1080) | |
Camera | • Cisco TelePresence PrecisionHD design • Resolutions: 1080p30 and 720p60 • Auto focus • Integrated privacy shutter • Document camera mode • Multicoated all-glass optics • 1/3-in., 2.1 megapixel CMOS sensor | EX90 • Horizontal field of view: 45°-65° • Vertical field of view: 40°-27° • Focus distance 0.3-infinity • Optical, motorized zoom EX60 • Horizontal field of view: 50° • Vertical field of view: 29° • Focus distance 0.1-infinity |
Audio system | • Two stereo front speakers • Integrated full-range microphone • One 3.5-mm line-in jack for PC or other audio source • Two 3.5-mm jack for headset • Wideband handset • Bluetooth-ready | • Integrated subwoofer (EX90 only) • Support for Performance Mic 20 (EX90 only) • HDMI audio input/output (EX90 only) |
User interface | Cisco TelePresence touch screen • Eight-inch projected capacitive touch screen • Resolution: 800 x 480 | |
Language support | English | |
Physical dimensions (H x L x D) | Cisco TelePresence System EX90 main unit: 21.4 x 22.3 x 6.8 in. (54.5 x 56.7 x 17.3 cm)Cisco TelePresence System EX60 main unit: 20.0 x 20.5 x 5.4 in. (50.8 x 52 x 13.8 cm) | • Cisco TelePresence touch screen: 1.7 x 9.0 x 5.7 in. (4.4 x 22.8 x 14.5 cm) • Cisco TelePresence touch screen with headset: 3.0 x 11.4 x 7.4 in. (4.4 x 22.8 x 14.5 cm) • Cable length: 47 in. (120 cm) |
Weight | Cisco TelePresence System EX90 main unit: 24.2 lb (11.0 kg) Cisco TelePresence System EX60 main unit: 12.9 lb (5.85 kg) | • Cisco TelePresence touch screen: 1.4 lb (0.64). • Cisco TelePresence touch screen with handset: 2.1 lb (0.94 kg) |
Power | Autosensing power supply100-240 VAC, 50/60 HzEX90: 150 watts max EX60: 75 watts max | |
Temperature range | Operating temperature and humidity: • Ambient temperature: 32 to 95°F (0 to 35°C) • Relative humidity (RH): 10 to 90% • Storage and transport temperature at RH 10-90% (noncondensing): -4 to 140°F (-20 to 60°C) | |
Approvals and compliance | • Directive 2006/95/EC (Low-Voltage Directive) - Standard EN 60950-1 • Directive 2004/108/EC (EMC Directive) - Standard EN 55022, Class A - Standard EN 55024 - Standard EN 61000-3-2/-3-3 • Approved according to UL 60950-1 and CSA 60950-1-07 • Complies with FCC15B Class A | |
Bandwidth | H.323/SIP up to 6 Mbps point-to-point | |
Video standards | • H.261 • H.263 • H.263+ • H.264 | |
Video features | • Widescreen: 16:9 • Advanced screen layouts • Intelligent video management • Local auto layout | |
Live video resolutions (encode/decode) | • 176 x 144@30 fps (QCIF) • 352 x 288@30 fps (CIF) • 512 x 288@30 fps (w288p) • 576 x 448@30 fps (448p) • 768 x 448@30 fps (w448p) • 704 x 576@30 fps (4CIF) • 1024 x 576@30 fps (w576p) • 640 x 480@30 fps (VGA) • 800 x 600@30 fps (SVGA) • 1024 x 768@30 fps (XGA) • 1280 x 1024@30 fps (SXGA) • 1280 x 720@30 fps (720p30) | • 1280 x 768@30 fps (WXGA) • 1920 x 1080@30 fps (1080p30)* • 1440 x 900@30 fps (WXGA+)* • 1680 x 1050@30 fps (WSXGA+)* • 1600 x 1200@30 fps (UXGA)* • 512 x 288@60 fps (w288p60)* • 768 x 448@60 fps (w448p60)* • 1024x576@60 fps (w576p60)* • 1280x720@60 fps (720p60) * Requires premium resolution option |
Audio standards | • G.711 • G.722 • G.722.1 • 64/128 kbps MPEG4 AAC-LD • AAC-LD stereo | |
Audio features | • CD-quality 20-kHz stereo • Acoustic echo canceling • Automatic gain control • Automatic noise reduction • Active lip synchronization | |
Dual stream | • H.239 (H.323) dual stream • BFCP (SIP) dual stream • EX90 supports resolutions up to 1080p in both main stream and dual stream simultaneously • EX60 supports resolutions up to 720p in both main stream and dual stream simultaneously | |
Protocols | • H.323 • SIP | |
Network interfaces | • Internal 2-port Ethernet switch • One LAN/Ethernet (RJ-45) 10/100/1000 Mbps for PC • One LAN/Ethernet (RJ-45) 10/100/1000 Mbps for LAN | |
Other interfaces | • Bluetooth for future applications • Two USB device for future applications (EX90) • One USB device for future applications (EX60) | |
IP network features | • Domain Name System (DNS) lookup for service configuration • Differentiated Services (QoS) • IP adaptive bandwidth management (including flow control) • Auto gatekeeper discovery • Dynamic playout and lip-sync buffering • H.245 DTMF tones in H.323 • Date and time support with Network Time Protocol (NTP) • Packet loss-based downspeeding • DNS-based URI dialing • TCP/IP • Dynamic Host Configuration Protocol (DHCP) • IEEE 802.1x network authentication • IEEE 802.1q VLAN | |
Firewall traversal | • Cisco TelePresence Expressway Technology • H.460.18 and H.460.19 Firewall Traversal | |
Embedded encryption | • H.323/SIP point-to-point • Standards-based: H.235 v2 and v3 and Advanced Encryption Standard (AES) • Automatic key generation and exchange • Supported in dual stream | |
Security features | • Management via Secure HTTP (HTTPS) and Secure Shell (SSH) Protocol • IP administration password • Menu administration password • Disable IP services • Network settings protection | |
MultiSite | EX90 only • 4-way 720p30 Continuous Presence (CP) MultiSite • Full individual audio and video transcoding • Individual layouts for each participant (CP layout without self view) • H.323/SIP/VoIP in the same conference • Best Impression (Automatic CP layouts) • H.264, encryption and dual stream from any site • IP downspeeding • Dial In/Dial out |
Производитель | Cisco |
Основные характеристики
- Audio features
- • CD-quality 20-kHz stereo
• Acoustic echo canceling
• Automatic gain control
• Automatic noise reduction
• Active lip synchronization - Audio standards
- • G.711
• G.722
• G.722.1
• 64/128 kbps MPEG4 AAC-LD
• AAC-LD stereo - Audio system
- • Two stereo front speakers
• Integrated full-range microphone
• One 3.5-mm line-in jack for PC or other audio source
• Two 3.5-mm jack for headset
• Wideband handset
• Bluetooth-ready - Autosensing power supply100-240 VAC, 50/60 HzEX90: 150 watts max EX60: 75 watts max
- Temperature range
- Cisco TelePresence System EX90 main unit: 21.4 x 22.3 x 6.8 in. (54.5 x 56.7 x 17.3 cm)Cisco TelePresence System EX60 main unit: 20.0 x 20.5 x 5.4 in. (50.8 x 52 x 13.8 cm)
- • Cisco TelePresence touch screen: 1.7 x 9.0 x 5.7 in. (4.4 x 22.8 x 14.5 cm)
• Cisco TelePresence touch screen with headset: 3.0 x 11.4 x 7.4 in. (4.4 x 22.8 x 14.5 cm)
• Cable length: 47 in. (120 cm) - Cisco TelePresence touch screen • Eight-inch projected capacitive touch screen
• Resolution: 800 x 480 - Language support
- Components
- Fully integrated unit including: • Codec
• Display
• Camera
• Microphone and loudspeakers
• Cables including: VGA-to-DVI-I cable, DVI-D cable, 3.5-mm jack audio cable, LAN cable, power adapter, and power cable - Display
- • EX90
• 24-in. LCD monitor
• Resolution: 1920 x 1200 (16:9)
• Contrast ratio: 1000:1
• Viewing angle: 160°
• Response time: 5 ms
• Brightness: 300cd/m2
• 5° - 15° tilt - Dual stream
- • H.239 (H.323) dual stream
• BFCP (SIP) dual stream
• EX90 supports resolutions up to 1080p in both main stream and dual stream simultaneously
• EX60 supports resolutions up to 720p in both main stream and dual stream simultaneously - DVI-IEX90: HDMI In
- Supported PC input resolutions
- Embedded encryption
- • H.323/SIP point-to-point
• Standards-based: H.235 v2 and v3 and Advanced Encryption Standard (AES)
• Automatic key generation and exchange
• Supported in dual stream - English
- Physical dimensions (H x L x D)
- EX90: SVGA (800 x 600) to WUXGA (1920 x 1200)EX60: SVGA (800 x 600) to 1080p (1920 x 1080)
- Camera
- Firewall traversal
- • Cisco TelePresence Expressway Technology
• H.460.18 and H.460.19 Firewall Traversal - H.323/SIP up to 6 Mbps point-to-point
- Video standards
- IP network features
- • Domain Name System (DNS) lookup for service configuration
• Differentiated Services (QoS)
• IP adaptive bandwidth management (including flow control)
• Auto gatekeeper discovery
• Dynamic playout and lip-sync buffering
• H.245 DTMF tones in H.323
• Date and time support with Network Time Protocol (NTP)
• Packet loss-based downspeeding
• DNS-based URI dialing
• TCP/IP
• Dynamic Host Configuration Protocol (DHCP)
• IEEE 802.1x network authentication
• IEEE 802.1q VLAN - MultiSite
- EX90 only • 4-way 720p30 Continuous Presence (CP) MultiSite
• Full individual audio and video transcoding
• Individual layouts for each participant (CP layout without self view)
• H.323/SIP/VoIP in the same conference
• Best Impression (Automatic CP layouts)
• H.264, encryption and dual stream from any site
• IP downspeeding
• Dial In/Dial out
- Network Interfaces
- • Internal 2-port Ethernet switch
• One LAN/Ethernet (RJ-45) 10/100/1000 Mbps for PC
• One LAN/Ethernet (RJ-45) 10/100/1000 Mbps for LAN - Operating temperature and humidity: • Ambient temperature: 32 to 95°F (0 to 35°C)
• Relative humidity (RH): 10 to 90%
• Storage and transport temperature at RH 10-90% (noncondensing): -4 to 140°F (-20 to 60°C) - Approvals and compliance
- Other interfaces
- • Bluetooth for future applications
• Two USB device for future applications (EX90)
• One USB device for future applications (EX60) - Product compatibility
- Fully compatible with standards-compliant telepresence and video systems
- Protocols
- • H.323
• SIP - Security features
- • Management via Secure HTTP (HTTPS) and Secure Shell (SSH) Protocol
• IP administration password
• Menu administration password
• Disable IP services
• Network settings protection - Software compatibility
- Cisco TelePresence Software Version TC4.0 or later
- Weight
- Cisco TelePresence System EX90 main unit: 24.2 lb
(11.0 kg) Cisco TelePresence System EX60 main unit: 12.9 lb
(5.85 kg) - Производитель
- Cisco
- • 176 x 144@30 fps (QCIF)
• 352 x 288@30 fps (CIF)
• 512 x 288@30 fps (w288p)
• 576 x 448@30 fps (448p)
• 768 x 448@30 fps (w448p)
• 704 x 576@30 fps (4CIF)
• 1024 x 576@30 fps (w576p) - • 1280 x 768@30 fps (WXGA)
• 1920 x 1080@30 fps (1080p30)*
• 1440 x 900@30 fps (WXGA+)*
• 1680 x 1050@30 fps (WSXGA+)*
• 1600 x 1200@30 fps (UXGA)*
• 512 x 288@60 fps (w288p60)*
• 768 x 448@60 fps (w448p60)*
• 1024x576@60 fps (w576p60)*
• 1280x720@60 fps (720p60)
* Requires premium resolution option - • Cisco TelePresence PrecisionHD design
• Resolutions: 1080p30 and 720p60
• Auto focus
• Integrated privacy shutter
• Document camera mode
• Multicoated all-glass optics
• 1/3-in., 2.1 meg - EX90 • Horizontal field of view: 45°-65°
• Vertical field of view: 40°-27°
• Focus distance 0.3-infinity
• Optical, motorized zoom
EX60 • Horizontal field of view: 50°
• Vertical field of view: 29°
• Focus distance 0.1-infinity - • Cisco TelePresence touch screen: 1.4 lb (0.64).
• Cisco TelePresence touch screen with handset: 2.1 lb (0.94 kg) - Power
- • Directive 2006/95/EC (Low-Voltage Directive) - Standard EN 60950-1
• Directive 2004/108/EC (EMC Directive) - Standard EN 55022, Class A - Standard EN 55024 - Standard EN 61000-3-2/-3-3
• Approved according to UL 60950-1 and CSA 60 - Bandwidth
- • EX60
• 21.5-in. LCD monitor (with LED backlight)
• Resolution: 1920 x 1080 (16:9)
• Contrast ratio: 1000:1
• Viewing angle: 170°
• Response time: 5 ms
• Brightness: 225cd/m2 - PC and second-source video input
- • H.261
• H.263
• H.263+
• H.264 - Video features
- • Integrated subwoofer (EX90 only)
• Support for Performance Mic 20 (EX90 only)
• HDMI audio input/output (EX90 only) - User interface
- • Widescreen: 16:9
• Advanced screen layouts
• Intelligent video management
• Local auto layout - Live video resolutions (encode/decode)
